Twinca dumpersTwinca ES-800

Twinca ES-800

Rechargeable Battery Powered High Tip Dumper

  • High loading capacity of 800kgs
  • 'Scissor Lift' High Tip mechanism
  • 5-6 hours recharge time
  • 8 hours run time

Overview

The ES-800 has a low gross weight and operates on wheels (instead of tracks) for increased speed and minimal ground damage. The oscillating steering axle increases traction on difficult terrain.

Powered by 2 x 12v/150ah batteries, this high tip dumper will continue to work at full capacity for an 8-hour shift and recharge in just 5-6 hours. The ES-800 is the largest Twinca Electric Dumper model. If you are looking for a smaller capacity the Twinca ES-500 could the right electric dumper for your needs.

The heavy duty ‘scissor lift’ high tipping mechanism eliminates the need for ramps and struggles to quickly and safe transfer material into skips or vehicle bodies.

As well as being able to carry 800kg of materials, the ES-800 can precisely pour concrete or screed with the addition of the concrete pourer attachment (optional extra).

See the ES-800 technical information below.

Technical data

Dimensions and weight
Width865 mm
Length2063 mm
Height1053 mm
Machine weight488 kg
Working height
Steering height1170 mm
Height load platform top3081 mm
Height load platform bottom scissors up1394 mm
Power
Battery2 x 12 V /150 Ah
Capacities
Capacity content volume400 L
Capacity content weight800 kg
Consumables
Hydraulic oilViskositet 32
